The UFM-C-Compact manual workstation is a powerhouse for precision assembly in small production runs, offering unparalleled accuracy in the micrometer range with a reproducibility of +/- 0.001 mm. Its compact design eliminates the need for an external electric cabinet, making it ideal for space-constrained environments. Available in two series, it handles forces from 50 N to 30 kN. The system is fast, flexible, and perfect for new applications, offering intuitive programming via UFM V5.xx software. Combining multiple work steps into a single process, it ensures 100% quality assurance with fast changeover times—ideal for efficient, clean, and quiet operations.
| Series S | Force | Stroke | Speed | Weight | |||||
|---|---|---|---|---|---|---|---|---|---|
| 0 – 3 kN | 60 – 200 mm | 250 – 400 mm/s | 60 – 70 kg |
| Series M | Force | Stroke | Speed | Weight | |||||
|---|---|---|---|---|---|---|---|---|---|
| 0 – 30 kN | 310 – 330 mm | 250 – 300 mm/s | 330 – 350 kg |
IGBT press-fit assembly
High positional accuracy requirements for press-fit pins
Full-process force-displacement envelope monitoring required throughout the press-fit operation
PROMESS precision force control enables reliable control and monitoring throughout the entire press-fit process, ensuring consistent part quality and full process traceability.
